Mount-Type

Ring-Mount, Rail-Mount

Reticle

4.I, CD-I, LD--I

Objective

1-6x
Magnification

9.6-24 mm
Effective objective lens diameter

9.6-4.0 mm
Exit pupil diameter

95 mm
Exit pupil distance

42.5-6.8 m/100m
Field of view

23.8-3.9 °
Field of view degrees

23.4 °
Field of view apparent

-3 to +2 dpt
Diopter adjustment

90 %
Light transmission

2.8-12
Twilight factor acc. to ISO 14132-1

Measurement

0.54 / 15
Impact point correction per click (in / mm)

2 / 72
2 / 72
Max. elevation / windage adjustment range (m/100m / in/100yds)

Digital

M 27x0.75
Objective filter thread

Twilight factor at medium brightness: 1,400; daylight factor at medium brightness: 180
Operating time

Size & Weight

296 mm
Length in mm.

440 g
460 g
Weight

30 mm
Central tube diamete

Environment & Conditions

-20 to +55 °C
Functional temperature

-30 to +70 °C
Storage temperature

13 ft / 4 m water depth (inert gas filling)
Submersion tightnessr

Illumination

Twilight: 0 - 32 / Day: 33 - 64
Brightness levels
