Mount-Type

Ring-mount, Rail-mount

Reticle

4A-I

Objective

2.5-15x
Magnification

24.0-56 mm
Effective objective lens diameter

9.5-3.8 mm
Exit pupil diameter

95 mm
Exit pupil distance

16.5-2.7 m/100m
Field of view

9.4-1.5 °
Field of view degrees

23.2 °
Field of view apparent

-3 to +2 dpt
Diopter adjustment

91 %
Light transmission

7.1-29
Twilight factor acc. to ISO 14132-1

50-∞ m
Parallax correction

Measurement

0.36 / 10
Impact point correction per click (in / mm)

1.8-1 / 64.8-36
Max. elevation / windage adjustment range (m/100m / in/100yds)

Digital

M 58x0.75
Objective filter thread

Twilight factor at medium brightness: 1,400; daylight factor at medium brightness: 180
Operating time

Size & Weight

367 mm
Length in mm.

655 g
665 g
Weight

30 mm
Central tube diameter

Environment & Conditions

-20 to +55 °C
Functional temperature

-30 to +70 °C
Storage temperature

13 ft / 4 m water depth (inert gas filling)
Submersion tightness

Illumination

Twilight: 0 - 32 / Day: 33 - 64
Brightness levels
